Geze Door Closer TS-2000 | Home and office Decor interior Designs
GEZE TS-2000 series is a robust, adjustable overhead door closer ideal for medium-to-large swing doors requiring controlled, repeatable closing with options like back-check and hold-open for tailored performance.
Key Features
Design & Operation
- Hydraulic closing mechanism – ensures soft, controlled door closing and consistent performance.
- Link arm configuration – mounts above the door for a sleek appearance and stable operation.
- Versatile mounting – suitable for right or left-hand doors without flipping components.
Adjustability
- Closing force adjustable – variable from EN size 2 to 4 to match door weight and width.
- Adjustable closing speed & latching action – fine-tunes how quickly the door closes and how it “pulls in” at the end of travel.
- Backcheck (on some variants like the NV BC) – slows the door if it’s opened forcefully, protecting the door/structure.
Performance & Standards
- Designed for doors up to approx. 1100 mm width (varies by model/installation).
- Conforms to EN 1154 standards for door closers.
Application
- Internal and external swing doors where controlled closing is important.
- Suitable for commercial buildings, offices, schools, and public spaces.
- Available with optional hold-open function or back-check versions for enhanced performance.
Installation Notes
- Mounts on the frame or leaf side depending on door design.
- Link arm and body are typically installed at the top of the door.
- Adjustable via front-accessible valves for tuning closing speed and latching.
₹190.00
GEZE TS-2000 is a hydraulic overhead door closer with a link arm, engineered for reliable and controlled closing of single-leaf doors in commercial and residential settings. It provides smooth, adjustable closing action and can be fitted with accessories such as backcheck and hold-open features depending on the version.
Application
- Internal and external swing doors where controlled closing is important.
- Suitable for commercial buildings, offices, schools, and public spaces.
- Available with optional hold-open function or back-check versions for enhanced performance.
| Size |
|---|
| 1100 mm |
Related Products
With its well-thought-out design, the GEZE Flush Bolt With Fixing Screws, Size 300 mm seamlessly integrates with a wide range of fittings and fixtures. It is easy to install and maintain, ensuring smooth functionality even in high-traffic or demanding conditions. The durable construction resists wear and tear, while the finish ensures resistance to corrosion and scratches. Whether used in contemporary or traditional settings, the GEZE Flush Bolt With Fixing Screws, Size 300 mm delivers a perfect balance of security, performance, and visual appeal.
Material & Finish:
- Stainless steel finish — corrosion-resistant, durable for long-term use.
- Comes with fixing screws for installation.
Operation:
- Manual slide bolt — simple push-slide action to lock/unlock.
- Surface mount installation — bolt body mounted on the door edge/frame surface.
Common Uses:
- Provides extra security on interior or exterior doors.
- Suitable for residential homes, offices, shops, storerooms.
- Often used on gates or heavy swing doors where additional fastening is needed.
Installation & Function
- Bolt slides horizontally into a keeper/strike plate fixed on the door frame.
- Easy to install with included screws; aligns with the strike for smooth engagement.
- Can be used alongside other door hardware (locks/handles) for layered security.
About This Item
- Provides effective, slump-free sealing in joints up to 35mm wide
- Proven 4-hour fire resistance
- Offers up to 52dB acoustic rating
- Permanent seal for low-movement joints, dry lining, and partitions
- Easily smoothed for a smooth surface finish
- Available in white, brown, and grey
- Can be painted after curing
- Supplied in 310ml cartridges for standard mastic guns
- 3 Cartridges
About This Item-Fire Rated Glass Manufacturer
Fire Resistance
Being one such premium glass supplier for Fire Rated Glasses, we offer Fire Rated Glass Manufacturer that can withstand high temperatures and prevent fire and smoke from spreading for a given time of 120 minutes, ensuring added safety.
Safety Assurance
Our fire-rated glass maintains critical fire barriers that lead to further enhanced safety of a building while providing a fire-rated environment in both commercial and residential settings.
Clear Visibility with Protection
Our glass opposes traditional fire barriers in that it allows for complete visibility without compromising on fire performance-the very criteria for the needs of new generation architects.
Durable Construction
Made with either tempered or laminated layers, our Fire Rated Glass Manufacturer
has ample strength to resist impacts and is trusted by every reputed manufacturer of Fire Rated Glass.
Applications
In doors, windows, partitions, curtain walls, and more, our products offer adaptable fire protection for diverse building types.
Natural Light Transmission
Our products allow the ingress of natural light into interiors while assuring extreme safety against fires.
Code Compliant
Being an extremely reliable Fire Rated Glass Manufacturer, we guarantee that our products comply with all national and international fire safety norms.
GEZE TS-1000 C is an overhead door closer with a link arm, designed to control the closing of internal single-leaf doors smoothly and reliably. It is a versatile, adjustable hydraulic closer commonly used in commercial and residential interior settings.
Key Features
Application
- Suitable for single-leaf doors (internal use).
- Works on both right and left hand doors without conversion.
- Can be installed on the door leaf hinge side or on the transom (opposite hinge side).
- Maximum door leaf width up to ~950 mm.
Adjustable Performance
- Closing force is adjustable between EN sizes 2 and 3 by rotating the link arm’s bearing block.
- Closing speed can also be adjusted hydraulically to control how fast the door closes.
- Hydraulic latching action (the final pull-in of the door) is adjustable for precise control.
Design & Standards
- Identical design for both DIN left and right doors, simplifying installation.
- Compact dimensions (approx. 215 × 44 × 52 mm).
Typical Uses
✅ Offices, hotels, schools, residential interiors
✅ Doorways where controlled closing and adjustable speed are desired
✅ Situations requiring reversible mounting for either hand of door
✅ Fits standard doors up to about 950 mm wide (some installations up to ~1100 mm with adjustments)
About This Item
• Easy to fit with high-tack self-adhesive tape applied
• No machining required • Durable resilient fins and central bulb • Cold smoke and acoustic seal
• Surface fixed to door frame with fitted self-adhesive tape
• Unique design is both hardwearing and highly effective as an acoustic barrier
• Minimum of 34-35dB can be achieved using standard FD30 and FD60 doors
• Successfully tested for cold smoke sealing as well as acoustic performance
• Co-extruded with robust rigid PVC mounting elements
• Available in standard length of 2100mm.
GEZE Pull Handle H-Type is a door handle designed for commercial and heavy-duty applications, featuring a robust H-shaped design that provides strong grip and visual symmetry. It is typically used on glass doors, wooden doors, metal doors, and entry doors where a bold and easy-to-grip handle is required.
Design
- H-Type Shape: A distinctive “H” configuration with two vertical bars joined by a horizontal cross-bar, offering a balanced and ergonomic grip.
- Modern Appearance: Clean lines and geometric form suit contemporary architectural designs.
Construction & Materials
- Commonly made of stainless steel or brushed metal finishes, ensuring high durability, resistance to corrosion, and long life.
- Polished or satin finishes available depending on the model.
Ergonomics
- Comfortable to grasp from multiple angles due to its shape and spacing.
- Suitable for both left and right swing doors since the handle design is symmetrical.
Typical Uses
- Commercial entrances (offices, shops, showrooms)
- Interior doors in corporate or hospitality environments
- Glass doors (often paired with patch fittings or floor springs)
- Main entrance doors that require a bold architectural look
Sizes & Variants
- Available in a range of lengths (e.g., 600 mm, 800 mm, 1200 mm, etc.) depending on door height and design requirements.
- Clearances and mounting centers vary by model.
Installation
- Installed through-bolt from one side of the door to the other.
- Compatible with glass thickness adapters when used on glass doors.
- Mounting hardware typically included.
About This Item
• Simple to install
• High-tack self-adhesive backing
• Retrofit design
• No machining necessary
• Compression seal
• Available in a roll of 50m.
About This Item
• Demonstrated performance in various internationally recognized tests
• Compatible with double-acting doorsets featuring radiused meeting stiles
• Non-standard colors available upon request
• Standard length: 10m.
• Available in standard sizes: 10mm x 2mm, 15mm x 2mm.
• Black brush pile smoke seal
About This Item
• Demonstrated performance in various internationally recognized tests
• Compatible with double-acting doorsets featuring radiused meeting stiles
• Non-standard colors available upon request
• Standard length: 2100mm
• Available in standard sizes: 10mm x 4mm, 20mm x 4mm.
• Black brush pile smoke seal
About This Item
• Premium aluminum threshold seal
• Seals gaps up to 13mm
• Easy installation with slide-and-click mechanism
• Adjustable with a slot head screwdriver
• 30-minute fire rating
• Outstanding noise reduction of up to 34dB
• Available in 5 standard lengths: 730mm, 830mm, 930mm, 1030mm, 1130 and 1230mm
• Optional end plates and cover plates
• Tested for 200,000 opening and closing cycles
About This Item
- Tolerates temperatures up to 1100°C
- Available in white and black finishes
- Proven performance for up to 245 minutes in glazed steel door sets
- Provides 50% compression to eliminate glass rattle
- Easy to apply with open self-adhesive
- Tested with various glass types as per Certifire/fire test requirements
- Dry glazing system, no cleaning required after installation
- 3 mm thickness
- 22 m coil
